Recommend for AMD Ryzen Processor, Socket AM4, 60x60x28mm PWM Fan, Aluminum Fins with Heatpipe directly contact CPU, Active Cooler for 2U Server and up, Support CPU power up to 165 Watts Heat Dissipation
CPU Support AMD® Ryzen
CPU Socket
AM4
Solution
2U Server and Up
Dimensions
107 x 78 x 67 mm
Weight
400 g
Material
Aluminum Stacked Fin with Heat Pipes directly contact CPU
Fan Dimension
60 x 60 x 28 mm
Speed
At Duty Cycle 20%: 1500±10% RPM
At Duty Cycle 50%: 3500±10% RPM
At Duty Cycle 100%: 7000 RPM
Bearing
Double-Ball
Rated Voltage
12V
Power
At Duty Cycle 20%: 0.6 W
At Duty Cycle 50%: 2.16 W
At Duty Cycle 100%: 7.2 W
AIr Flow
At Duty Cycle 20%: 8.8 CFM
At Duty Cycle 50%: 20.3 CFM
At Duty Cycle 100%: 40.5 CFM
Noise Level
At Duty Cycle 20%: 16.0 dBA
At Duty Cycle 50%: 32.9 dBA
At Duty Cycle 100%: 47.5 dBA
Air Pressure
At Duty Cycle 20%: 0.7 mm-H2O
At Duty Cycle 50%: 3.6 mm-H2O
At Duty Cycle 100%: 14.3 mm-H2O
Lead Wire Pin Out
Pin1- (-)
Pin2- (+)
Pin3- (Techometer/Signal output)
Pin4- (PWM)
